Ezzy Legacy


Click on sail image for zoom view

THE 2013 LEGACY SERIES

An all new “stripped down” collection from Ezzy.

At the heart of the Legacy is the bare elements of David’s design philosophy. The Legacy Sails deliver all the power, range and stability you have come to expect from Ezzy but with a twist. We keep a utilitarian philosophy with the Legacy by removing all the extra features present on our premiere sails.

A high performance wave and freeride collection that delivers awesome performance for your more budget-minded customers.


"The Legacy has everything you need and nothing you don't need. The Legacy reminds me of the days when I was getting full-on custom sails built for competition, they had none of the marketing b.s. that people think they need but don't really. This sail is a classic Ezzy design, pure and simple. "

Kevin Pritchard - Ezzy Team Rider

Color Choices - Based on Head Color

Gold | Black

A portion of every sail we sell goes to help schools in Sri Lanka.
Click on the image to read more about the Ezzy Foundation!

Legacy Rigging Video

LEGACY SAIL SPECS

2013 Ezzy Legacy Luff Luff Boom Boom No. of Suggested Weight
Size (sq.m.) min max min max Battens Mast Kgs
4.2 378 380 149 157 5 370/27/17 2.72
4.7 402 404 157 165 5 400/25/19 2.92
5.2 421 423 165 173 5 400/25/19 3.13
5.8 441 443 171 178 5 430/25/21 3.33
6.5 452 455 189 198 6 430/25/21 3.88
7.5 475 478 202 212 6 460/25/25 4.14


Note on Ezzy Masts

Ezzy Sails work great with the Ezzy Mast system, but also work with a variety of other brand masts (RDM and regular diameter). You could contact your mast maker and see if the bend of your non-Ezzy mast is compliant.

Ezzy mast bend curves are tip: 75% to 79% and base: 62% to 65%

Note: this is not carbon content. This is percentage bend relative to the midpoint bend.

For further info on Ezzy Mast sizing, please refer to our Mast Configurator Tool

Our removable, 316 stainless steel tack pulley can be replaced with our 316 stainless D-ring for those who prefer a grommet with a pulley hook.


  • Every Ezzy Legacy is rigged and fine tuned in our factory before shipping.
  • At Ezzy we offer unmatched customer service. Email us at [email protected] and you will get a personal response within 12 hours.

  • Clarence

    IS there any chance of uploading (or emailing me) photos of the different sized sails, as it would appear the cut changes from the large down to smaller sizes. There is no shop within several 100kms of here where I can view the sails to check it out myself.
    Thanks

    • ezzysails

      thanks for asking Clarence! The 4.2-5.8 are all based upon the exact same shape as our Tiger wave sail. The 6.5 and 7.5 are based upon the shape of the Cheetah except there is only one batten below the boom.
      The line drawings here:
      http://www.ezzy.com/sails/2013-sails/2013-ezzy-legacy/
      are based upon the profile of the 4.2, 4.7, 5.2, and 5.8

      This image is of a 6.5, and the 7.5 will have the same outline.
      http://www.ezzy.com/ezzy2013/wp-content/uploads/2013/02/legacy4.jpg

      Does this answer your question? Feel free to email me directly at [email protected]!

      Regards,
      tim

      • Erwan Couëdelo

        Hi,
        I have got a Cheetah 7.5 that I feel very happy with.
        I would like to buy a smaller Ezzy sail but I am a bit hesitant regarding the sail size.
        Given that I am riding a 121 litres freerace board and a 95 litres freewave board, what do you recommend?
        A 5.8 Legacy would do? Thanks for your reply.
        Erwan (Windsurf spot: Poetto beach – Sardinia – Italy)

        • ezzysails

          thank you for the message Erwan! I think going from a 7.5 to a 5.8 would be a nice way to scale your sizes, but it would depend upon your local conditions and your skill level. This is when a local dealer would be best to ask. As far as going from a 7.5 to a 5.8, I would be very comfortable with the scaling.
