THE 2014 EZZY TIGER
Last years 5 batten Tiger moves forward into '14 completely unchanged. The Tiger comes with color fusion film, a beautiful graphic layout, and both our Calibrated Downhaul System and our standard leech downhaul gauges.
The Tiger has been designed to fit a wide range of masts, and most importantly, it comes with a tested and proven design that is sure to please the more
traditional sailor looking for the classic power, stability, and durability of an Ezzy sail.
“Late yesterday afternoon I had a chance to take the Ezzy Tiger out to test the upper limit of its range (4.7). Several guys my size were on 4.2, so I rigged the 4.7 for high wind and went and played in the swells with them. Wow was that an eye opener for all of us. I was not expecting the control, balance and how relaxed I was being on “too big” of a sail. The range of the Ezzy Tiger is amazing…and it was the talk of the beach at the end of the day.”
Gary Morris – Baja, Mexico
Color Choices - Based on Head Color
Green | Black | Tangerine
A portion of every sail we sell goes to help schools in Sri Lanka.
Click on the image to read more about the Ezzy Foundation!
RIGGING GUIDE AND CATALOG
2014 TIGER SAIL SPECS
| 2014 Ezzy Tiger | Luff | Luff | Boom | Boom | No. of | Ezzy Mast | Base | Weight |
| Size (sq.m.) | Min | Max | Min | Max | Battens | Base/Top | Extension | Kgs |
| 2.9 | 315 | 317 | 127 | 132 | 5 | 340 / 340 | 6 cm | 2.55 |
| 3.3 | 336 | 338 | 137 | 142 | 5 | 340 / 340 | 6 cm | 2.71 |
| 3.5 | 349 | 351 | 140 | 146 | 5 | 340 / 340 | 11 cm | 2.84 |
| 3.7 | 359 | 361 | 146 | 152 | 5 | 340 / 370 | 6 cm | 2.92 |
| 4.0 | 369 | 371 | 150 | 156 | 5 | 340 / 370 | 16 cm | 3.01 |
| 4.2 | 380 | 382 | 152 | 158 | 5 | 370 / 370 | 12 cm | 3.08 |
| 4.5 | 390 | 392 | 155 | 161 | 5 | 370 / 400 | 7 cm | 3.17 |
| 4.7 | 403 | 405 | 159 | 165 | 5 | 370 / 400 | 20 cm | 3.28 |
| 5.0 | 416 | 418 | 163 | 170 | 5 | 400 / 400 | 18 cm | 3.39 |
| 5.2 | 422 | 424 | 166 | 173 | 5 | 400 / 400 | 24 cm | 3.46 |
| 5.5 | 432 | 434 | 171 | 177 | 5 | 400 / 430 | 19 cm | 3.57 |
| 5.8 | 440 | 442 | 173 | 180 | 5 | 430 / 430 | 12 cm | 3.67 |
| 6.0 | 450 | 452 | 177 | 184 | 5 | 430 / 430 | 22 cm | 3.78 |
| 6.3 | 455 | 457 | 183 | 190 | 5 | 430 / 430 | 27 cm | 3.86 |
| 6.9 | 485 | 487 | 185 | 192 | 5 | 460 / 460 | 27 cm | 4.12 |
INDIVIDUAL TIGER RIGGING VIDEOS
1. Tiger Quick Rig
2. Tiger Calibration System for Non Ezzy Masts
3. Tiger Rigging for Ezzy Masts
4. Threading the Pulley
5. Batten Tension
6. Derigging
Note on Ezzy Masts
Ezzy Sails work great with the Ezzy Mast system, but also work with a variety of other brand masts (RDM and regular diameter). You could contact your mast maker and see if the bend of your non-Ezzy mast is compliant.
Ezzy mast bend curves are tip: 75% to 79% and base: 62% to 65%
Note: this is not carbon content. This is percentage bend relative to the midpoint bend.
For further info on Ezzy Mast sizing, please refer to our Mast Configurator Tool
Our removable, 316 stainless steel tack pulley can be replaced with our 316 stainless D-ring for those who prefer a grommet with a pulley hook.
- Every Ezzy Legacy is rigged and fine tuned in our factory before shipping.
- At Ezzy we offer unmatched customer service.
Email us at [email protected] and you will get a personal response within 12 hours.
